QuinLED Diff-Adv

(0 review)

Designed for extended distances between a QuinLED controller and LED setup, the QuinLED Diff-Adv is the perfect solution for more complex installations.

QuinLED Diff-Adv, a step up of the previously introduced Diff-Solo, offers a more advanced system to send your LED data signals over long distances. Instead of sending a single LED data signal via UTP it is able to send up to 4 data signals over the same UTP connection.

To provide highest flexibility of the LED Data signal distribution the receiver boards are designed as "midpoint" boards which allows them to be "daisy chained" and configured based on your choice of output. You can even choose to duplicate the same LED data signal to multiple points.

quinled
$ 16.99 $ 16.99
$ 16.99

$ 0.00 / Units
  • Diff-Adv
Add to cart
Add to wishlist
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days
Contact Us

Feature highlights:

  • 4 LED data signals over a single UTP cable (distance up to 500m/1800ft)
  • Receiver-Midpoint boards allow you to chain Receiver-Midpoint boards and get each LED data signal where you need it
  • 5v-48v support for both Sender and Receiver-Midpoint boards
  • Receiver-Midpoint boards with 1 or 2 LED data outputs
  • Receiver-Midpoint-2 features built-in power distribution and fusing
  • Level-Shifter + 33R resistor on all outputs of the Receiver-Midpoint boards

What do you need to buy for your setup?

The Diff-Adv system is a set of boards you can mix and match yourself. You always need a QuinLED Diff-Adv Sender-4 board but can then combine it with several Receiver-Midpoint-1 or Receiver-Midpoint-2 boards.

Some example setups, for more details info check: https://quinled.info/quinled-diff-adv-wiring-guide/

Additional Information

Videos on the Diff-Adv


More information:

3D Printed Cases:

Some accessories you made need for you install
Some links are affiliate links and we may earn a small commission when you purchase through the link,  your price does not change and it doesn't affect any deals or coupons either.

Power Supply:

We always suggest Meanwell power supplies, very reliable and actually give you the power they state.


Fuses:

You will need ATO encase you miss-wire or blow the included unit, it's always better to have some spares.  There is a lot of cheap versions on fuses on amazon, I've used the below fuses without much issue but if you want a quality fuse stick with Littlefuse or Bussman Fuses

  ​ ​ ​

​


Misc. Accessories:

We sell a variety of accessories to help with your install like out Self-Closing Spit Braided Loom and our Dual Wall Adhesive Lined Heat Shrink to help make water tight connections
